Pipes with Check Valves - Locates pipes that have the Has Check Valve? input attribute set to True.Inactive Elements - Locates elements that have been set to Inactive.Elements With SCADA Data - Locates elements that are have SCADA data associated with them.See Using the Duplicate Labels Query for more information. Duplicate Labels - Locates duplicate labels according to parameters set by the user.

Input Queries include a number of queries that allow you to find elements that satisfy various conditions based on input data specified for them.

Find Initially Isolated Elements - Locates elements that are not connected or cannot be reached from any boundary condition.

In order to service the element, this will identify where shut off points and isolation valves are located. Run the query to locate the nearest isolation valves.

Isolate - Select an element that needs to be serviced.

Trace Downstream - Locates all the elements connected downstream of the selected upstream element.

Trace Upstream - Locates all the elements connected upstream of the selected downstream element.

The query reports the shortest path between the two nodes based upon the shortest number of edges.

Find Shortest Path - Select a Start Node and a Stop Node.

Find Disconnected - Locates all the disconnected elements in the network by reporting all the elements not connected to the selected element.

Find Adjacent Links - Locates all link elements connected upstream or downstream of the selected element or elements.

Find Adjacent Nodes - Locates all node elements connected upstream or downstream of the selected element or elements.

Find Connected - Locates all the connected elements to the selected element in the network.

Network Trace Queries include the following:

Duplicate Pipes - Identifies instances in the model where a pipe shares both end nodes with another pipe.

Pipes Missing Nodes - Identifies which pipes are missing either one or both end nodes.

The tolerance value can be set for the maximum distance from the pipe where the node should be considered as a pipe split candidate.

Pipe Split Candidates- Identifies nodes near a pipe that may be intended to be nodes along the pipe.

Dead End Junctions - Identifies junctions that are only connected to one pipe.

Dead End Nodes - Identifies nodes that are only connected to one pipe.

Orphaned Isolation Valves - Identifies isolation valves that are not connected to a pipe in the model.

Orphaned Nodes - Identifies nodes that are not connected to a pipe in the model.Crossing Pipes - Identifies pipes that intersect one another with no junction at the intersection.Nodes In Close Proximity - Identifies nodes within a specific tolerance.Network Review Queries include the following: Network queries include ∺ll Elements queries for each element type, allowing you to display all elements of any type in the Network Navigator. Categories and the queries contained therein include: The Network Navigator provides access to a number of predefined queries grouped categorically, accessed by clicking the button. When this toggle button is on, elements returned by a query will be highlighted in the drawing pane to increase their visibility. Selects the listed elements in the drawing pane and performs a zoom extent based on the selection. Removes the selected element from the list.

Watergems tanks has check valve windows#

Specifies the magnification level at which elements are displayed in the drawing pane when the Zoom To command is initiated.Ĭopies the elements to the Windows clipboard. Zooms the drawing pane view to the selected element at the magnification level specified in the Zoom Level menu.Ĭhooses the element below the currently selected one in the list. If there is already a Query listed in the list box, it can be run when the Execute icon is clicked. Once a query is selected, it can be executed when you click the > icon. Choose the element sets to use in the query.
